SPINNER millimeter wave testing components give you unprecedented flexibility in creating millimeter wave testing environments. Our solutions are mechanically extremely flexible and uncompromisingly good in technical terms.
The number of applications in the millimeter wave range is growing steadily, and with them the need for appropriate testing equipment. The portfolio of proven products that SPINNER has created for VNA applications are rounded out by these components, which have been specifically developed for millimeter waves. A special benefit for users of this product range is its significantly expanded range of uses.
One of the great challenges in the development of new communication technologies like 6G in the sub-millimeter section such as the D-band frequency range is the flawless and reliable electrical interconnection technology.
Until recently, narrowband rectangular waveguide components were the only option available. Then, the coaxial 0.8 mm connector system (IEC 61169-64) emerged as a standardized solution, eliminating the need for costly plumbing and providing improved bandwidth and measurement capabilities. However, SPINNER goes a step further.
Introducing our revolutionary 0.8 mm coaxial connector system with strengthened outer conductor, offering unmatched precision and performance up to 165 GHz. Our advanced design features a durable 0.8 mm interface that ensures damage-free repeated connections while delivering superior electrical characteristics for maximum measurement accuracy.
SPINNER 0.8 mm Coaxial Connectors
Compared to standard 0.8 mm connectors, our connectors are highly reliable over extended use, maintaining quality, efficiency and full compatibility.
Our state-of-the-art technology features exceptional flexibility and is suitable for measurement applications in all industries. Our system is one of the most versatile options available, providing high-frequency measurement capabilities up to 165 GHz. For unparalleled precision and performance, choose SPINNER’s advanced “strengthened 0.8 mm coaxial connector system".
Download SPINNER 0.8 mm Coaxial Connector System brochure (2 MB)
SPINNER’s 1.0 mm high precision coaxial calibration kit, connectors, and adapters are engineered for a frequency range from DC up to 120 GHz and offer excellent performance.
The 1.0 mm coaxial connectors are standard in RF labs worldwide. These include vector network analyses (VNA) or measurements in the millimeter-wave range. The 1.0 mm coax interface is also known as the Type W connector.
In fact, they are must-haves for engineers who perform measurements in the range up to 120 GHz. It provides measurement accuracy, versatility and ease of use for coaxial measurements, microwave communication systems, defense and aerospace applications, where precise and accurate signal transmission is critical.
However, their conventional design suffers from a problem: the pitch is too coarse, i.e. the axial distance between the thread walls is too great.
The nut that mates with a 1.0 mm connector loosens practically from being looked at. Calibration problems are therefore literally built-in, often making it necessary to repeat entire test series. Besides the unnecessary extra costs this incurs, it’s a major source of frustration.
1.0 mm Coaxial Connector Portfolio
SPINNER provides multiple solutions to address the common issue of 1.0 mm coaxial connectors loosening over time.
Hence, we offer a comprehensive range of adapters to ensure optimal mechanical connections across various frequency ranges. SPINNER provides adapters from 1.0 mm to 1.85 mm for measurements up to 70 GHz on a 110/120 GHz VNA, as well as adapters for the 1.35 mm E-connector. Our ruggedized test port adapters for the 1.0 mm interface are particularly recommended for achieving reliable and stable connections.
For laboratories that rely on 1.0 mm connectors, we offer various ruggedized test port adapter specifically designed for one-millimeter coax connections.
These adapters use a larger thread to achieve a secure mechanical lock, effectively blocking unintended transverse or torsional forces that could damage the delicate 1.0 mm coaxial connection. As a result, once a test setup is assembled and calibrated, it can be consistently relied upon to perform as intended.
Download SPINNER 1 mm Coaxial Connector System brochure (2 MB)
SPINNER mmWave waveguide-to-coaxial adapters for the V, E, W and F bands let you directly connect waveguide-based measurement network topologies to the coaxial ports of VNA or millimeter-wave-range extender modules.
Start testing faster with these new adapters from SPINNER. They save time with ruggedized coaxial interfaces for directly connecting millimeter waveguides to the coaxial ports of mmWave VNAs. Ultralow losses are guaranteed.
In lab environments, you need to have the right interfaces handy: for waveguide-to-coaxial or coaxial-to-waveguide transitions and with male or female coaxial connectors as required. These convenient solutions save time and let you focus on your testing work.
Download SPINNER mmWave waveguide-to-coaxial adapters brochure (3 MB)
Learn more / Product finder
The Robust Precision Interface for DC to 90 GHz
As the market for millimeter wave sensors for self-driving vehicles expands, the demand for proper RF connections in testing environments is also growing. Reliable coaxial interface connections are crucial for achieving good RF performance, especially in E-band applications. A common frustration in RF laboratories is unwanted unlocking of the 1.00 mm coaxial thread performing time-consuming calibrations. This spawned the idea of a 1.35 mm connector the “E Connector” with a precise metric thread like the 1.85 mm connector plus an integrated time-saving push-pull capability.
Download SPINNER E-Connector brochure (3 MB)
SPINNER 1.35 mm - E Connectors
SPINNER EasyLaunch is a PCB signal-tapping adapter that is designed to reliably pick up millimeter wave signals from PCBs. The flush-mounted SPINNER EasyLaunch avoids compromising the PCB surface and ensures optimal measurement results. It is available with either a coaxial or a waveguide connector.
SPINNER EasyLaunch PCB Adaptor
SPINNER EasyLaunch Flyer
SPINNER EasySnake performs the function of a flexible dielectric waveguide. However, classic waveguides are typically rigid, which places considerable constraints on the design of test configurations. The SPINNER EasySnake overcomes this by combining the flexibility of a conventional RF test cable with the excellent low-loss transmission characteristics of a conventional waveguide system. It can be flexibly bent and moved in any direction while delivering excellent measurement results.
SPINNER EasySnake
SPINNER EasySnake Flyer
